JJ 550uF, 385V, radiaal

JJ 550uF, 385V radiaal d=35mm x h=68mm

Operating temperature: -25°C + 70°C Rated voltage: 385VDC + SOOVDC Rated capacitance: 47p F + 800pF Capacitance tolerance ( at 100Hz, 20°C): -10% +30% Dissipation factor ( at 100Hz, 20°C): 0,15 + 0,25 Leakage current (after 5 minutes application of rated voltage): I = 0,005.C.U I - current [pA] C - rated capacitance [pF] U - rated voltage [V]

The aluminum case capacitors are supplied with PVC sleeve insulation and a safety vent located on end-deck.

Load life:
Load life is 1000 hours (at maximum operating temperature, at rated voltage and AC current load as per Table 1). After 1000 hours of the above application of rated voltage and current load, capacitors must meet the following characteristics requirements: Capacitance change <= +/- 15% of initial value Tan d «= 150% of initial value Leakage current <=initiaI value

AC Load: The maximum AC load at maximum operating temperature (70”C) i.
