Finder Relais DPDT , 125V 2A, 6V

Relays, type Finder Dual-In-Line-Relais 2,0 A for low breaking capacity

Compact dimensions: 20.3 x 10.1 x 11.4 mm
grid according to wiring diagram

Function: 2 x changeover contacts
Constant/inrush current: 3.0 A/2.0 A
Rated/switching voltage: 125 VAC/250 VAC
Breaking capacity AC 1/AC 15 (230 V): 125 VA/25 VA
Switching current DC 1: 2.0 A/30 V, 0.3 A/110 V
Minimum switching load: 10 mW (0.1 V/1.0 mA)
Contact material: AgNi+Au (5.0 µm)
Useful mechanical life DC: 10 x 10 exp6 switching cycles
Electrical life AC 1: 100 x 10 exp3 switching cycles
Insulation coordination EN 61810-5: 1.2 kV/2
Electric strength coil/contact (1.2/50 µs): 1.5 kV
Response/release time: 6.0 ms/2.0 ms
Ambient temperature: –40 to +85 °C
Relay protection class: RT III
Certifications: CSA, UL, GOST
